Home ProductsHigh Lumen LED Work Light

Aluminum Housing 96w High Lumen LED Work Light 5200lm

Certification
China Guangzhou Hanma Electronics Technology Co. Ltd certification
China Guangzhou Hanma Electronics Technology Co. Ltd certification
I'm Online Chat Now

Aluminum Housing 96w High Lumen LED Work Light 5200lm

Aluminum Housing 96w High Lumen LED Work Light 5200lm
Aluminum Housing 96w High Lumen LED Work Light 5200lm Aluminum Housing 96w High Lumen LED Work Light 5200lm Aluminum Housing 96w High Lumen LED Work Light 5200lm Aluminum Housing 96w High Lumen LED Work Light 5200lm

Large Image :  Aluminum Housing 96w High Lumen LED Work Light 5200lm

Product Details:
Place of Origin: Guangzhou, Guangdong
Brand Name: HANMA
Certification: CE, RoHS, IP67, IP69K,R10
Model Number: HML-8654
Payment & Shipping Terms:
Minimum Order Quantity: 500 SET
Price: USD$1-200/ 500 SET
Packaging Details: White box for inner packing,and carton for outer packing
Delivery Time: 45-60 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 1-100000 PCS/45 days

Aluminum Housing 96w High Lumen LED Work Light 5200lm

Description
LED Chip:: OSRAM Power: 96W
Lens Material: Polycarbonate Housing Material: Aluminum
Voltage: DC 10-30V Warranty: 1 Year
High Light:

96w High Lumen LED Work Light

,

5200lm High Lumen LED Work Light

,

IP69K LED Work Light

2pcs UTV ATV Off Road Lighting 96w High Lumen Led Work Light 5200lm

5200lm High lumen led work light, 4.5 inch 96 Watt led work light, Off Road Lights for Truck Trator ATV, SUV, UTV

Quick Detail:


Tech Data
Model HML-8654
LED Qty 9 PCS
LED Type OSRAM
LED Power 30-54W
LED Color white
Input Voltage DC10-30V
Color Temperature 5700K
Lumens Output 2780-5200 lm
Working Temperature -35℃~+70℃
Storage Temperature -40℃~+100℃
Life span >30000hrs
Certification CE, RoHS, IP67,IP69K,EMC
IP Grade IP67,IP69K
Housing Color Black
Housing Material Extruding aluminum
Net Weight 290G±5%
Dimension 114.4*100.91*45mm
Package 350*320*260mm (20pcs/box)





About this item



90° FLOOD Led Light: With OSRAM Led chips, this lights with 90° illumination range gives out abandunt brightness for clear visibility, increasing safe hugely for your night riding, as well as your driving in rainny foggy weather.


STAINLESS steel Led light Pods: With durable aluminum housing and 304 stainless steel mounting bracket, this 4.5 inch light pod can withstand different harsh environment, keeping you from rust annoyance.



Product Warranty: Any quality issue is under one year of replacement warranty. We stand behind our products.



Equipped with Temperature Control System(TCS): when turned on, the light can work at maximum output power and lumens;


UNIVERSAL FIT Off Road Lights: It is can be widely used for engineering machinery,agriculture, mining, forestry, industry lighting ,UTV, ATV, etc




Model LED CHIPS LEDS Power Effective Lumen Amp(12V/24V) OPTIONAL BEAM
HML-8754/8654 OSRAM 6w 9 30-54W 2780-5200m 5.32/2.76 FLOOD





Application:



1. Off-Road vehicles: 4×4, ATV, SUV, UTV, truck, Fork lift, trains, boat, bus, and tanks
2. Engineering vehicles: Excavator, road roller, bulldozer, crane and mining truck etc.
3. Vehicles: Fire engine, police cars, rescue vehicle, communication vehicle, military command vehicle etc.


Aluminum Housing 96w High Lumen LED Work Light 5200lm 0





What is TCS ?



When the light housing temperature reaches 75℃ as time goes on,TCS will automatically reduce the light output power and lumens until reach
a thermal balance to prevent overheat and extend product lifespan;When the light housing temperature below 75℃,such as whendriving(well air exchange) or in low temperature environment, the TCS will increase the current,power and lumens of the light to achieve optimal performances.





BEAM PATTERN

Aluminum Housing 96w High Lumen LED Work Light 5200lm 1





What Will You Get ?



2x LED WORK LIGHT

2x BRACKET

Factory Introduction



Snow plow head light Heated Lens DOT EMARK SAE 5" x 7" Led Headlights, Position,Turn Signal Hi/Low  beam 2

Hanma Co., Ltd has been engaged in the auto light business since 2005. In 2009, Hanma entered the

field of high power LED auto light including LED work light successfully and became one of the earliest

companies in this industry in China.

The product series include led light bar, led work light, led driving light, offroad lighting, LED Pod lights,

LED Head lights, LED remote search lights.


With the rapid development, Hanma moved to the Baiyun District of Guangzhou, China, and built a bigger

factory in the September of 2013, covering an area over 16,000 square meters and equiping with advanced

equipment and facilities. This promotes Hanma’s production capacity to 1,000 pcs/day for light bars and

6,000pcs/day for work lights.

Besides, Hanma has introduced talents of R&D, QC, PMC, Sales and new method of management to make

Hanma a strong team. At present, Hanma has passed the quality systerm of ISO 9001:2008 and get the

SGS certificate. Hanma’s products are EMARK, CE, RoHS, IP67 certificated. Owing to its effort and customers’ support.

Hanma is now a leader in high power LED auto light industry in China.


Hanma and its products have very good reputation worldwide. So far, Hanma has established cooperation with

customers in more than 80 countries, serving 167 customers in 33 countries worldwide, 10+ world top brands;

30+ regional top brands.


Hanma will continue to devote itself into new product research and development, provide goods with outstanding

quality and create more values for you and the world! Your satisfaction is what we pursue!



Production Progress(work lights for Example)

Snow plow head light Heated Lens DOT EMARK SAE 5" x 7" Led Headlights, Position,Turn Signal Hi/Low  beam 3

Package Progress

Snow plow head light Heated Lens DOT EMARK SAE 5" x 7" Led Headlights, Position,Turn Signal Hi/Low  beam 4

Warehouse

Snow plow head light Heated Lens DOT EMARK SAE 5" x 7" Led Headlights, Position,Turn Signal Hi/Low  beam 5

Certifications

Snow plow head light Heated Lens DOT EMARK SAE 5" x 7" Led Headlights, Position,Turn Signal Hi/Low  beam 6

Hanma’s products are EMARK, CE,SAE DOT,FCC,SMETA, RoHS, IP67, IP69K,ISO 9001 and TS16949 certificated.

And Hanma is a National High-Tech Enterprise, AEO certified company by Chinese customs, SMETA Audit Factory and BSCI Audit Factory.



Qualification

HANMA is platinum partner to CREE company.
HANMA is Platinum Strategic partners to OSRAM-Industry exclusive.

HANMA is the biggest customer to OSRAM and CREE in the automotive LED light aftermarket.
2019 Vendor award from Harbor Freight Tools ( top 5 among 2000 vendors)

ISO9001 ODM Car Hood Curved Single Row Light Bar 51 Inch 10530 Lumen 8

Showroom

ISO9001 ODM Car Hood Curved Single Row Light Bar 51 Inch 10530 Lumen 9



Exhibition



Snow plow head light Heated Lens DOT EMARK SAE 5" x 7" Led Headlights, Position,Turn Signal Hi/Low  beam 9

WHY CHOOSE US


1. High quality: We are professional OEM and ODM suppliers and we are experienced in control control.All our products have completed aging test before package and have to be passed 4 steps QC tested before shipping.
2. Reasonsable price: We are factory and aim at middle and high end,so we could offer you high quality products but reasonable price!
3. One time delivery:Delivery the goods in the confirmed time!For faster delivery,we have our own cooperation Expree company to save you time to get the products on this issue
4. Professional sales:Good communication in patient and well known about the stage lighting products.
5. Warranty: The product warranty period is 1 years. In this ONE years, you just need to send us a video or picture which records the damaged part of the lights.Then we will send Brand -NEW replacement FREE OF CHARGE with your next order.



FAQ

Q1:How do I know your lights are of the highest quality?

A:With IP67, IP69K ratings, the research has already been done for you! These standards give you clear cut pass/fail scenarios to ensure only the toughest of the tough get passed these guys, including water, temperature, pressure, and sheer brute force.

Q2: What is light beam spread pattern, and what is best for me?

A:Flood - Wide-spread light to illuminate the side and front of your rig. Perfect for those who want a wider cone of light than a spot.

Spot - Great for those who need those piercing beams of light that seem to travel forever.

Drving - This is perfect for mounting on your front bumper or If you have a car, this is great for mounting in the lower grill or in the opening underneath your front bumper.



Q3: Do you accept OEM and ODM?
A: We are professional OEM and ODM suppliers and we are experienced in control control.All our products have completed aging test before package and have to be passed 4 steps QC tested before shipping.
